1020180000 | WDU 4 BL | W-SERIES - Feedthrough terminal block | Clamping Yoke Technology

Weidmuller | 1020180000 | WDU 4 BL | W-SERIES - Feedthrough terminal block | Clamping Yoke Technology - Standard 1 Tier

Weidmuller feedthrough terminal with clamping yoke technology (screw-in connection) you are guaranteed contact safety. Weidmuller W-Series 1020180000 (WDU 4 BL) is the perfect solution to add to your applications. This application's max voltage is 400 V with a current of 24 A in a dark beige colour.

The W-Series from Weidmuller screw connection has long been an established connection element to meet exacting demands regarding reliability and functionality. Plus the W-Series is still setting standards.

• Version: Feed-through terminal, Screw connection, 4 mm², 800 V, 32 A, blue
• Order Number: 1020180000
• Type: WDU 4 BL
• Product Dimension: 46.5 x 60 x 6.1mm
• Continuous Operating Temperature min…max: -60?…130?
• Max. Voltage (ATEX): 800 V
• Current (ATEX): 32  A
• Rail: TS 35
• Wire connection AWG Min...Max: 10…26
• Standards: IEC 60947-7-1
• Type of mounting: SNAP-ON

Additional Information

The W-Series offers many convincing benefits and comes in four different designs. Thanks to the range of models and real flexibility, our modular terminal blocks with clamping yoke technology can be used in various applications. Whatever your requirements for the control cabinet are: our screw connection system with patented clamping yoke technology ensures the ultimate in contact safety.
