ACW5M119012https://download.schneider-electric.com/files?p_Doc_Ref=103002&p_File_Type=rendition_4000_pngPRESSOSTAT - WITH 0,07 TO 7,6 BARS - ACW5. Label: OsiSense XM - range of product: OsiSense XM - materials in contact with fluid: phosphor bronze - pressure sensor size: 5.2 bar - adjustable range of switching point on falling pressure: 0.07-5.2 bar - adjustable range of switching point on rising pressure: 0.37-6.2 bar - pressure sensor name: ACW - pressure actuator: bellows - electrical circuit type: control circuit - pressure sensor type: electromechanical pressure sensor - product specific application: for regulation between 2 thresholds - scale type: adjustable differential - contacts type and composition: 1 C/O snap action - cable entry: 1 entry tapped for ISO M20 cable gland - fluid connection type: G 1/4 (female) conforming to ISO 228 - Range Presentation: Electronic pressure sensors for control circuit Pressure transmitters and pressure switches are characterised by their ceramic pressure measuring cell for controlling air, fresh water, sea water, hydraulic oils, corrosive fluids - -1 to 400 bars (-14.4 to 5800 psi), without adjustment XML-G range - -1 to 600 bars (-14.4 to 870 psi), with simple adjustment XML-E range with user-friendly configuration and adjustment XML-F range Electromechanical Pressure and Vacuum switches for control circuit For controlling air, fresh water, sea water, hydraulic oils, corrosive fluids and viscous products - -1 to 500 bars (-14.5 to 7250 psi) with fixed differential* XMLA range with adjustable differential* XMLB , XMLC range with 2 stages with fixed differential at each threshold XMLD range Dedicated to air and water up to 25 bars (362.5 psi) with adjustable differential* XMX and XMA range
Electromechanical Pressure switches for power circuit For controlling water,and/or air up to 25 bars FTG fixed differential* FSG, FSG 2NE, FYG and XMP adjustable differential**fixed differential: detection of a single threshold *adjustable differential: regulation between 2 thresholds - Range Benefits: One of the most comprehensive catalogues of industrial and power pressure sensors on the market, including a user-friendly electronic transmitter sensor which can be configured in complete simplicity, with unrivalled flexibility of modification during operation. - Range Application Presentation: - Pressure control or monitoring on water pumps, compressors, moulding presses, injection moulders, grinding machines, machining centres, etc
PRESSOSTAT - WITH 0,07 TO 7,6 BARS - ACW5. Label: OsiSense XM - range of product: OsiSense XM - materials in contact with fluid: phosphor bronze - pressure sensor size: 5.2 bar - adjustable range of switching point on falling pressure: 0.07-5.2 bar - adjustable range of switching point on rising pressure: 0.37-6.2 bar - pressure sensor name: ACW - pressure actuator: bellows - electrical circuit type: control circuit - pressure sensor type: electromechanical pressure sensor - product specific application: for regulation between 2 thresholds - scale type: adjustable differential - contacts type and composition: 1 C/O snap action - cable entry: 1 entry tapped for ISO M20 cable gland - fluid connection type: G 1/4 (female) conforming to ISO 228 - Range Presentation: Electronic pressure sensors for control circuit Pressure transmitters and pressure switches are characterised by their ceramic pressure measuring cell for controlling air, fresh water, sea water, hydraulic oils, corrosive fluids - -1 to 400 bars (-14.4 to 5800 psi), without adjustment XML-G range - -1 to 600 bars (-14.4 to 870 psi), with simple adjustment XML-E range with user-friendly configuration and adjustment XML-F range Electromechanical Pressure and Vacuum switches for control circuit For controlling air, fresh water, sea water, hydraulic oils, corrosive fluids and viscous products - -1 to 500 bars (-14.5 to 7250 psi) with fixed differential* XMLA range with adjustable differential* XMLB , XMLC range with 2 stages with fixed differential at each threshold XMLD range Dedicated to air and water up to 25 bars (362.5 psi) with adjustable differential* XMX and XMA range
Electromechanical Pressure switches for power circuit For controlling water,and/or air up to 25 bars FTG fixed differential* FSG, FSG 2NE, FYG and XMP adjustable differential**fixed differential: detection of a single threshold *adjustable differential: regulation between 2 thresholds - Range Benefits: One of the most comprehensive catalogues of industrial and power pressure sensors on the market, including a user-friendly electronic transmitter sensor which can be configured in complete simplicity, with unrivalled flexibility of modification during operation. - Range Application Presentation: - Pressure control or monitoring on water pumps, compressors, moulding presses, injection moulders, grinding machines, machining centres, etc
