DC CHOKE 2,2MH 19,2A

DC CHOKE 2,2MH 19,2A

VW3A4506https://www.cca.co.uk/image.php?filename=vw3a4506.jpg&stockcode=VW3A4506&category=vsd-accessories--spares&width=1000&height=1000DC choke - 2.2 mH - 19.2 A - for variable speed drive.Label:Altivar 71-product or component type:DC choke-range compatibility:Altivar 61,Altivar 71-device application:reduction of current harmonics-value of inductance:2.2 mH-[In] rated current:19.2 A-thermal losses:33 W-product compatibility:ATV61HU75N4,ATV71HU75N4,ATV71HU22M3,ATV71WU75N4,ATV71PU75N4Z,ATV61HU22M3-Range Presentation:200... 240 V single-phase
200... 240 V / 380... 690 V 3-phase, 50/60 Hz
- Speed regulation by flux vector control with or without sensor- Speed range: from 1 to 1 000 in closed loop mode with encoder feedback, from 1 to 100 in open loop mode- Graphic terminal: plain text, navigation button, configurable function keys, "Simply Start" menu ...- Protection of motor and of drive- "Power Removal ", ATEX safety functions- More than 150 functions available: PID regulator, brake control suited to travelling, hoisting and slewing movements...- Integrated EMC filter class A- Integrated Modbus and CANopen- I/O extension cards, interface cards for encoder- Communication cards: Fipio, Ethernet, Modbus Plus, Profibus DP, DeviceNet, Uni-Telway, INTERBUS- Controller Inside programmable card-Range Benefits:Make way for evolution! Unique range up to 630 kW, exceptional performance, advanced functions...
Open to all communication networks, applications, users... Altivar 71 provides ingenious solutions for all your particular requirements.-Range Application Presentation:High performance applications (constant torque):
- Material handling - Hoisting - Wood machines - Process machines - Textile machines - Packaging
GBP
Stock Code: VW3A4506
Call for availability on 0345 030 60 80
This item is Obsolete
119999.99£99,999.99 (exc VAT) per 1
£119,999.99 (inc VAT)
Quantity: - +

Product Description

DC choke - 2.2 mH - 19.2 A - for variable speed drive.Label:Altivar 71-product or component type:DC choke-range compatibility:Altivar 61,Altivar 71-device application:reduction of current harmonics-value of inductance:2.2 mH-[In] rated current:19.2 A-thermal losses:33 W-product compatibility:ATV61HU75N4,ATV71HU75N4,ATV71HU22M3,ATV71WU75N4,ATV71PU75N4Z,ATV61HU22M3-Range Presentation:200... 240 V single-phase
200... 240 V / 380... 690 V 3-phase, 50/60 Hz
- Speed regulation by flux vector control with or without sensor- Speed range: from 1 to 1 000 in closed loop mode with encoder feedback, from 1 to 100 in open loop mode- Graphic terminal: plain text, navigation button, configurable function keys, "Simply Start" menu ...- Protection of motor and of drive- "Power Removal ", ATEX safety functions- More than 150 functions available: PID regulator, brake control suited to travelling, hoisting and slewing movements...- Integrated EMC filter class A- Integrated Modbus and CANopen- I/O extension cards, interface cards for encoder- Communication cards: Fipio, Ethernet, Modbus Plus, Profibus DP, DeviceNet, Uni-Telway, INTERBUS- Controller Inside programmable card-Range Benefits:Make way for evolution! Unique range up to 630 kW, exceptional performance, advanced functions...
Open to all communication networks, applications, users... Altivar 71 provides ingenious solutions for all your particular requirements.-Range Application Presentation:High performance applications (constant torque):
- Material handling - Hoisting - Wood machines - Process machines - Textile machines - Packaging

Width96 mm
Height134 mm
Depth120 mm
